CR825 Multifunctional diesel fuel injection common rail test bench

I'm Online Chat Now

CR825 Multifunctional diesel fuel injection common rail test bench

China CR825 Multifunctional diesel fuel injection common rail test bench supplier

Large Image :  CR825 Multifunctional diesel fuel injection common rail test bench

Product Details:

Place of Origin: Shangdong
Brand Name: XBD
Certification: CE & ISO
Model Number: XBD-CR825

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: USD10000.00-15000.00 per set
Packaging Details: Plywood case
Delivery Time: 15-20 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 60 sets per month
Contact Now
Detailed Product Description
Product Name: Diesel Pump Injection Common Rail Test Bench Power: Electronic
Warranty: 12 Months Voltage: 380V
Usage: Test Common Rail System Color: Green
Packing: Plywood Case Weight: 1100kgs

CR825 Multifunctional diesel fuel injection common rail test bench

CR825 Multifunctional diesel fuel injection common rail test bench

















































The main function:

1. Test common rail injector

2. Test common rail pump

2. Test unit pump/pump nozzle

4. Test the HEU injector

5. Test the HUI actuator pump

6. Test the Carter 320D common rail pump

7. Maximum rail pressure 180-240 MPa

8. IQA code generation

9. Injection drive and system voltage monitor

10. Common rail with filtering function

11. Dual DRV configuration

12. High-voltage filter plugging reminder function

13. Oil tank and diesel mailbox integrated air conditioning strong refrigeration system

CR825 Multifunctional diesel fuel injection common rail test bench



Data of test bench

1 Supply voltage 380V AC, 220V AC (optional)
2 Phase 3 phase, single phase (optional)
3 Frequency 50Hz/60Hz
4 Current 25-45A (MAX)
5 Main motor power 11-22KW
6 Main motor speed range 0-4000RPM/MIN
7 Oil pump motor power/flow 0.19KW/10LMIN
8 Diesel pump motor power/flow 11KW/10LMIN
9 Control loop voltage DC12V/24V 350W
10 EUC internal boost 0-200V DC (MAX)
11 Oil tank volume 36L
12 Diesel fuel tank volume 45L
13 Oil temperature control method Heating/forced cooling
15 Flow meter (injection) 4-500ml/min
16 Flow meter (oil pump oil supply) 1-400L/H
17 Flow meter (oil) 5-600L/H
18 Motor and work surface center distance 125mm
19 Weight 1100kg
20 Appearance net size 2250*1280*1920mm
21 Package size 2350*1500*2100mm



Package

The package is wooden case or plywood case, if you need, we can also pack the products according to your demands.

CR825 Multifunctional diesel fuel injection common rail test bench







FAQ

Q: How many days to produce this test bench?

A: It need 5-20 days to produce the test bench.

Q:How can I pay for it?

A:We support TT payment, West Union, and L/C etc.

Q:How to sign an order?

A:We can sign an order offline or online on Ali.

Q:How long of warranty?

A:12 months

Q:Do you have some repairing tools?

A:Yes, we have many kinds of repairing tools for common rail injector and pump
