Two axle carriage semi-trailer

I'm Online Chat Now

Two axle carriage semi-trailer

China Two axle carriage semi-trailer supplier

Large Image :  Two axle carriage semi-trailer

Product Details:

Place of Origin: Tanan city, China
Brand Name: Wuyue
Certification: ISO
Model Number: TAZ9250X

Payment & Shipping Terms:

Minimum Order Quantity: 1 piece
Packaging Details: Nude packing
Delivery Time: 30 days after receiving 30% deposit by T/T
Payment Terms: L/C,T/T
Supply Ability: 20000 Unit/Units per Year
Contact Now
Detailed Product Description



Quick Details

  • Use: Truck Trailer
  • Type: Semi-Trailer
  • Material: Steel
  • Certification: ISO CCC GJB
  • Size: 12500x2500x3900mm
  • OEM No.: Z0
  • Max Payload: 30000
  • Place of Origin: Shandong, China (Mainland)
  • Brand Name: SINOTRUK
  • Model Number: TAZ9250X
  • Carriage Dimensions: 12300x2300x2100
  • Kingpin: 90# 3.5inch
  • Axle: FUWA brand, 13tons
  • Suspension: steel spring
  • Main structure: Longeron Q345 steel plate,500x140
  • Upper wing plate: 14mm
  • Lower wing plate: 14mm
  • Tool box: 1set, 800*600*500
  • Spare tire: 2pcs
  • Tire: 12R22.5,12 pieces



Specifications


1. Type:TAZ9250X
2. Dimensions
Overall size:12500×2500×3900mm
Carriage  Dimensions:12300×2300×2100
3. Loading capacity:30000 kg
4. Dead weight: 8000kg
5. Axle:Two axles, FUWA brand,13000kg class
6. Landing gear:JOST,C200
7. Kingpin:3.5’’ (90#)
8. Tire:12R22.5, 12 pieces
9. Suspension:Steel spring
10.Main structure:
Longeron: Q345 Mn steel plate; 500×140mm;
upper wing plate: 14mm; Lower wing plate: 14mm;
thickness:6mm, side longeron: 16# channel steel;
floor: chequered plate. 3mm
11.Corrugated sheet :1.2mm, 2 doors only in one side., with back door.
12. Tool box:1 set,  800×600×500mm
13. Spare tire support: 2 pieces, without spare tire.
