CRS-100 common rail injector tester

China CRS-100 common rail injector tester supplier

Large Image :  CRS-100 common rail injector tester

Product Details:

Place of Origin: Taian China
Certification: ISO9001
Model Number: CRS-100

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Packaging Details: wooden case
Delivery Time: 10 days
Payment Terms: T/T
Supply Ability: 100 sets a month
Contact Now
Detailed Product Description
Color: Green, Blue, Yellow Or On Request

CRS100 common rail injector tester imitate the diesel Engine ECU principle, provides high pressure fuel to common rail injector assembly. At the same time it provide Bosch, Denso, Delphi and other common rail system Control signal, drive common rail injector.CRS100 can measure common rail injector injection flow and return oil.

   Used to test common rail injector performance, including sealing, the atomization quality, injection flow and return oil, electromagnetic valve opening and closing. It is currently the simplest, the ideal test equipment.


Technical parameters

1. Max pressure tested: 32 mpa

2. Common rail injector controller:

   Range of pulse width: 100-5000Us

   Frequency range: 1-30 Hz

   Count range: 1-6000

   Testing injector: BOSCH, DENSO, DELPHI, SIEMENS (special order)

3. Pressure meter measuring range: 0-60 mpa

4. Working voltage 220V

5. Weight 50 Kg

6 Dimensions: length*width*height (mm): 432x375x670


cam box
