CR825 Multifunctional diesel fuel injection common rail test bench
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Product Name: | Diesel Pump Injection Common Rail Test Bench | Power: | Electronic |
|---|---|---|---|
| Warranty: | 12 Months | Voltage: | 380V |
| Usage: | Test Common Rail System | Color: | Green |
| Packing: | Plywood Case | Weight: | 1100kgs |
CR825 Multifunctional diesel fuel injection common rail test bench
The main function:
1. Test common rail injector
2. Test common rail pump
2. Test unit pump/pump nozzle
4. Test the HEU injector
5. Test the HUI actuator pump
6. Test the Carter 320D common rail pump
7. Maximum rail pressure 180-240 MPa
8. IQA code generation
9. Injection drive and system voltage monitor
10. Common rail with filtering function
11. Dual DRV configuration
12. High-voltage filter plugging reminder function
13. Oil tank and diesel mailbox integrated air conditioning strong refrigeration system
Data of test bench
| 1 | Supply voltage | 380V AC, 220V AC (optional) |
| 2 | Phase | 3 phase, single phase (optional) |
| 3 | Frequency | 50Hz/60Hz |
| 4 | Current | 25-45A (MAX) |
| 5 | Main motor power | 11-22KW |
| 6 | Main motor speed range | 0-4000RPM/MIN |
| 7 | Oil pump motor power/flow | 0.19KW/10LMIN |
| 8 | Diesel pump motor power/flow | 11KW/10LMIN |
| 9 | Control loop voltage | DC12V/24V 350W |
| 10 | EUC internal boost | 0-200V DC (MAX) |
| 11 | Oil tank volume | 36L |
| 12 | Diesel fuel tank volume | 45L |
| 13 | Oil temperature control method | Heating/forced cooling |
| 15 | Flow meter (injection) | 4-500ml/min |
| 16 | Flow meter (oil pump oil supply) | 1-400L/H |
| 17 | Flow meter (oil) | 5-600L/H |
| 18 | Motor and work surface center distance | 125mm |
| 19 | Weight | 1100kg |
| 20 | Appearance net size | 2250*1280*1920mm |
| 21 | Package size | 2350*1500*2100mm |
Package
The package is wooden case or plywood case, if you need, we can also pack the products according to your demands.
FAQ
Q: How many days to produce this test bench?
A: It need 5-20 days to produce the test bench.
Q:How can I pay for it?
A:We support TT payment, West Union, and L/C etc.
Q:How to sign an order?
A:We can sign an order offline or online on Ali.
Q:How long of warranty?
A:12 months
Q:Do you have some repairing tools?
A:Yes, we have many kinds of repairing tools for common rail injector and pump
